Rotary pump as a pump unit
Rotary pump as a pump unit
orCall +49 (0) 8161-48333
Specifications
| Manufacturer | KSB SE |
| Year | 2013 |
| Condition | Used |
| Stock Number | 204759JF |
| Additional title | on foundational plate |
| Pump capacity | 10 m³/h |
| Max pump head | 55 m |
| Rotational speed pump | 451 rpm |
| Rotational speed motor | 1770 rpm |
| Power | 5,5 kW // 6,3 kW |
| Current | 11,3/6,6 A // 10,9/9,9 A |
| Voltage | 400/690 V // 460/480 V |
| Frequency | 50 Hz // 60 Hz |
| Heating / Cooling | Ambient temperature limit: 20 °C |
| Material | Rotor casing 1.4409, Casing cover, rotors, rotos screw 1.4404, finish roughness 1,6 μm, bearing bracket cast iron |
| Base construction | mounted on base plate |
| Features | Tri-lobe rotary type, coupled pump, suction nominal and discharge nominal DN65 (APV Flange), connection position horizontal, mechanical seal, single internal, KSB-electric motor (rated power 5,5 kW (400/690 V, 50 Hz), motor const. B5) |
