cap bunker
cap bunker
orCall +49 (0) 8161-48333
Description
simultaneous placement of two feed containers, two extra feed containers included.
The feed containers filled with caps are placed on top of the tipping platform. From there they fall into the mobile hopper and finally into a longitudinal conveyor. When caps are requested, they are conveyed to a drop-in hopper and thus reach the conveyor belt. From there, the caps are conveyed into a pipeline with a blower, and from there they are moved to the closing unit.
Specifications
Manufacturer | Eckel & Sohn Maschinenbau |
Year | 1999 |
Condition | Used |
Stock Number | 208178BB |
Additional title | cap supply |
Operating pressure | 7 bar |
Power | 50 W |
Current | 0,62 A |
Voltage | 156 V |
Frequency | 50/25 Hz |
Compressed air | 100 l/min |
Length | 2,45 m |
Width | 1,9 m |
Height | 2,3 m |
Weight | 300 kg |
Operation / Control | Siemens Simatic S5-90U |
Base construction | stainless steel frame |
Features | total of four feed containers, electrical cabinet |
