Crate unpacker

Crate unpacker
or
Call +49 (0) 8161-48333
Description
Crate unpacker
Specifications
Manufacturer | Krones |
Year | 2005 |
Condition | Used |
Stock Number | 209911HG |
Additional title | Unpacking machine for glass bottles |
Performance approx. | 50000 bottles/h |
Air consumption | 0,0002 m³ / bottle |
Number of packing heads | 6 pc. |
Power | 24,5 kW |
Voltage | 230/400 V |
Frequency | 50 Hz |
Length | 6160 mm |
Width | 4120 mm |
Height | 5033 mm |
Weight | 2500 kg |
Formats | 0.5 l glass bottle (D=68.5 mm H=270 mm; Ale / Longneck), 0.33 l glass bottle (D=61 mm H=238 mm; Ale / Longneck) |
Running direction | across, right -> left |
Operation / Control | PLC, control box with touch panel |
Position | free standing |
Base construction | Square tube frame on spherical feet |
Features | 1 basic machine (lifting mechanism, horizontal linear unit, gripper head carrier, movement axes), 2 gripper head sets (frame with 6 ring gripper heads, 20 (24) ring grippers each, pulling device, manual changing device, container transport, container transport, safety device, electrical and pneumatic equipment |
Layer patterns | 6x20 across, 6x24 across, 20 plastic box (400 x 300 x 300 mm), 24 plastic box (400 x 300 x 270 mm), |
